• 800 x 480P resolution and wide screen viewing angle enable clear and intuitive screen display;
• The high-precision fingerprint recognition module allows for quick and accurate fingerprint collection while also protecting the privacy of the customer;
• 233PPS report rate ensures instant capture of every pen movement without any lagging;
• 2048 levels of pressure sensitivity enable users to get different lines as the pressure applied varies, therefore capturing more biometric information during the signing process;
• The battery-free EMR digital pen does not require charging or ink, bringing great flexibility;
• Owning strong compatibility, DS530S helps users sign the files in Word, Excel, PDF, and other formats and on the web pages of major browsers

Specifications

• Model
  DS530S
• Fingerprint
  192 x 192
• Panel Size
  5inch
• OS Support
  Windows 7 or later
• Interface
  USB-C
• Sensing Height
  10mm
• Accuracy
  -+0.5mm (Center); -+3mm (Corner)
• Report Rate
  233PPS
• Pressure Sensitivity
  2048 Levels
• Net Weight
  285g
• Dimension
  166.9 x 173.4 x 18mm
• Pen Technology
  Electromagnetic Resonance
• Color
  Charcoal grey
• Pen Resolution
  5080LPI
• Viewing Angle
  70 deg/70 deg (H)/50 deg/70 deg (V) (Typ.)(CR10)
• Response Time
  10ms
• Brightness
  400 cd/m Squared
• Contrast Ratio
  800:1
• Active Area
  108 x 64.8 mm
• LCD Type
  TFT
• Resolution
  800 x 480 (16:9)
